HD695WV RG-6 Cable (White) 95% Shield 305M | By JJSATS

Product Description: ACE 32IPQAM

32IPQAM IP to 32 QAM Modulator is the latest generational Mux-scrambling-modulating all-in-one device developed. It has 32 multiplexing channels, 16 scrambling channels and 32 QAM modulating channels, and supports maximum 1024 IP input through the GE port and 16 non-adjacent carriers (50 MHz to 960 MHz) output through the RF output interface. The device is also characterized with high integrated level, high performance and low cost. This is very adaptable to newly generation CATV broadcasting system.

Main Features: ACE 32IPQAM

• Modular design, 1U chassis supports up to 3 modules.
• Fully complying with EN300 429/ITU-T J.83A.
• 32 GE ports support backup input, up to 1024 IP inputs, network de-bounce.
• Supporting UDP protocol, uni-cast and multi-cast, IGMP V2/V3.
• Single input IP max value 108 Mbps, amount input coding stream value 840 Mbps.
• Direct-connection input or be multiplexed to 8 output channels.
• Any input channel to any output channel multiplexing, amount of output PID per input is 256 (maximum).
• PCR fine-tuning.
• PSI / SI editing and inserting.
• 32 QAM modulation carrier output, 4 adjacent channel carrier output, 2 RF output.
• 32 QAM modulation constellation optional.
• Symbol rate range: 5.0 Msps to 7.0 Msps.
• RF output range: 48 MHz to 860 MHz in 1 Hz step.
• RF output level attenuation: -14 dBm to 6 dBm in 0.5 dB step.
• MER: greater than or equal to 40 dB.
• Network management system.
