RG-11 Cable (Black) 95% Shield 305M | By JJSATS

Product Description: IP to 32 QAM Modulator (Model: 32IPQAM)

The 32IPQAM IP to 32 QAM Modulator is the latest generational Mux-scrambling-modulating all-in-one device developed. It has 32 multiplexing channels, 16 scrambling channels, and 32 QAM modulating channels, and supports maximum 1024 IP input through the GE port and 16 non-adjacent carriers (50MHz~960MHz) output through the RF output interface. The device is also characterized with high integrated level, high performance and low cost. This makes it very adaptable to the newly generation CATV broadcasting system.

Main Features:

• Modular design, 1U chassis supports up to 3 modules.
• Fully complying with EN300 429/ITU-T J.83A.
• 2 GE ports support backup input, up to 1024 IP inputs, and network de-bounce.
• Supports UDP protocol, unicast and multicast, IGMP V2/V3.
• Single input IP max value is 108Mbps, with the input amount coding stream value at 840Mbps.
• Direct-connection input or can be multiplexed to 8 output channels.
• Any input channel can be mapped to any output channel multiplexing, with the amount of output PID per input up to 256 (maximum).
• PCR fine-tuning.
• PSI / SI editing and inserting.
• 32 QAM modulation carrier output, 4 adjacent channel carrier output, 2 RF output.
• 32QAM modulation constellation is optional.
• Symbol rate range: 5.0Msps7.0Msps.
• RF output range: 48MHz860MHz in 1Hz step.
• RF output level attenuation: -14dBm6dBm in 0.5dB step.
• MER is greater than or equal to 40dB.
• Includes Network management system.
