BOSE L1 Pro32 – Portable Line Array System with Sub2 Powered Bass Module & Sound System for Ballroom, Seminar Hall, Meeting Room & Conference Room | By JJSATs

Name: BOSE L1 Pro32 – Portable Line Array System with Sub2 Powered Bass Module & Sound System for Ballroom, Seminar Hall, Meeting Room & Conference Room | By JJSATs
Brand: BOSE
SKU: NOSKU006
Availability: InStock

Attribute:

SKU : NOSKU006

Add to wishlist

Compare

Categories : All Product ,

Brand : BOSE

Product Overview
- Product Type: Portable Line Array System
- Applications: Ideal for ballrooms, seminar halls, meeting rooms, and small to mid-sized venues that require high-quality sound and powerful bass.
L1 Pro32 (Line Array) Specifications
- Dimensions:
  - Array: 85" H x 4.5" W x 4.5" D (216 H x 11.5 W x 11.5 D cm)
  - Power Stand: 42" H x 10.2" W x 10.7" D (107 H x 26 W x 27 D cm)
- Weight:
  - Array: 13 lbs (5.9 kg)
  - Power Stand: 28 lbs (12.7 kg)
- Frequency Response: 40 Hz 16 kHz
- Maximum SPL: 128 dB (peak)
- Coverage Pattern: 180° horizontal coverage
- Connectivity:
  - Inputs: 2 x Combo XLR-1/4" inputs, 1 x 1/4" input, 1 x 1/8" (3.5 mm) aux input, 1 x Bluetooth streaming input
  - Outputs: 1 x Balanced XLR line output
- Key Features: Integrated 3-channel mixer, wireless control via the Bose Music app, modular design for portability.
Sub2 Powered Bass Module Specifications
- Dimensions (H x W x D): 27.3" x 12.5" x 21.7" (69.4 x 31.7 x 55.1 cm)
- Weight: 51.6 lbs (23.4 kg)
- Frequency Response: 37 Hz 180 Hz
- Maximum SPL: 123 dB (continuous), 129 dB (peak)
- Driver: 1 x 10" x 18" high-excursion woofer (RaceTrack transducer)
- Amplifier Power: 1,000 watts Class D
- Connectivity:
  - Inputs: 1 x XLR-1/4" combo input, 1 x ToneMatch input
  - Outputs: 1 x XLR line output, 1 x ToneMatch output
- Compatibility: Designed for seamless integration with the L1 Pro32.
Package Contents
- L1 Pro32 system components
- Sub2 Bass Module
- Power cables
- Quick start guide

BOSE L1 Pro32 with Sub2 Powered Bass Module
General System Specifications
Speaker Type	Portable Line Array System
Color Options	Black
L1 Pro32 (Line Array) Specifications
Dimensions	Array: 85" H x 4.5" W x 4.5" D (216 H x 11.5 W x 11.5 D cm) Power Stand: 42" H x 10.2" W x 10.7" D (107 H x 26 W x 27 D cm)
Weight	Array: 13 lbs (5.9 kg) Power Stand: 28 lbs (12.7 kg)
L1 Pro32 Audio Performance
Frequency Response	40 Hz 16 kHz
Maximum SPL @ 1m	128 dB (peak)
Coverage Pattern	180° horizontal coverage
L1 Pro32 Connectivity
Inputs	2 x Combo XLR-1/4" inputs 1 x 1/4" input 1 x 1/8" (3.5 mm) aux input 1 x Bluetooth streaming input
Outputs	1 x Balanced XLR line output
Bluetooth Version	Bluetooth 5.0
Bluetooth Range	Up to 30 ft (9 m)
L1 Pro32 Power
Power Supply	100 240V AC, 50/60 Hz
L1 Pro32 Features
Line Array Design	32 articulated 2 neodymium drivers for extended coverage and high-output performance
Built-in Mixer	Integrated 3-channel mixer with EQ, reverb, and ToneMatch presets
Wireless App Control	Bose Music app for wireless control and customization
Portability	Modular design for easy transport and setup
Durability	Rugged and durable construction for professional use
Sub2 Powered Bass Module Specifications
Speaker Type	Powered Bass Module
Color Options	Black
Dimensions (H x W x D)	27" H x 12" W x 21.5" D (69.2 H x 30.5 W x 54.5 D cm)
Weight	51.7 lbs (23.4 kg)
Sub2 Audio Performance
Frequency Response	37 Hz 200 Hz
Maximum SPL @ 1m	123 dB (peak)
Sub2 Connectivity
Inputs	1 x XLR-1/4" combo input
Outputs	1 x XLR line output 1 x SubMatch input/output
Sub2 Power
Amplifier	Integrated 1000-watt amplifier
Power Supply	100 240V AC, 50/60 Hz
Sub2 Features
Driver	10" × 18" high-excursion RaceTrack driver for powerful bass performance
Portable Design	Compact and lightweight for easy transport
Durability	Rugged enclosure with a steel grille for protection
Compatibility	Designed to pair seamlessly with the BOSE L1 Pro32 system via SubMatch connectivity
Additional Information
Warranty	2-year limited warranty
Accessories Included
Package Includes	L1 Pro32 system components Sub2 Bass Module Power cables Quick start guide
Optional Accessories
Optional Accessories	L1 Pro32 System Bag T4S/T8S ToneMatch mixer L1 Pro32 Slip Cover

ToneMatch Mixer Seminar Hall Conference Room Subwoofer Sound System for Ballroom BOSE JJSATs
