SMATV/MATV/CATV System

The ACE 1HD-1T is a compact and high-performance HDMI to COFDM modulator, designed to convert HDMI video and audio signals into a DVB-T RF output for digital TV broadcasting. This all-in-one device supports MPEG-4 AVC/H.264 video encoding and MPEG1 Layer II audio encoding, making it ideal for small CATV headend systems, hotel TV broadcasting, home entertainment, CCTV integration, and digital signage. It’s an excellent solution for transmitting HDMI sources such as satellite receivers, Blu-ray players, or surveillance cameras to DVB-T compatible TVs and STBs.

The ACE 01HD-1TC is a professional single-channel HDMI encoder that integrates encoding, multiplexing, and modulation into one compact unit. It supports QAM (DVB-C) or COFDM (DVB-T) output, making it a versatile solution for RF digital TV broadcasting. Ideal for hotel IPTV systems, apartment complexes, or small-scale CATV headend installations, this device ensures stable transmission and cost-effective performance.

The ACE 04HD-1T is a professional-grade 4-channel HDMI encoder and single OFDM modulator that combines encoding, multiplexing, and modulation into one compact unit. Supporting 4 HDMI inputs, it delivers high-quality RF output via 1 adjacent carrier (DVB-T standard), making it ideal for hotel TV systems, apartment blocks, and centralized RF headend solutions. Easily managed through a web-based interface, it offers reliability and performance in a cost-effective package.

The ACE 04HDO-4T is a compact, professional-grade device that integrates 4-channel HDMI encoding, multiplexing, and modulation into a single unit. Each input supports MPEG-4 AVC/H.264 video compression, with high-quality RF output via 4 COFDM carriers. This device supports IP output (MPTS) and is ideal for digital TV broadcasting in hotel headend systems, resorts, hospitals, and integrated IPTV environments.

The ACE 08HDO-4T is a professional-grade encoding and modulation device designed for digital RF broadcasting. It features 8 HDMI input channels and 4 COFDM RF outputs, making it perfect for distributing HD content over DVB-T networks. With MPEG-2 and H.264 encoding, MPTS IP output, and web-based management, this encoder is ideal for hotel TV systems, resorts, hospitals, and IPTV headend deployments.

GX-Blank Panel Fracarro – Metallic blank panel designed to cover and protect unused module slots in the GALAXIA IPTV headend chassis. Ensures optimal airflow and maintains a clean, professional appearance while safeguarding internal components.

GX-Front Panel Fracarro – High-quality front control panel designed for use with Fracarro's Galaxia IPTV headend systems. This panel provides quick and intuitive access to essential monitoring and control functions, ensuring system performance and operational reliability in professional broadcasting environments.

The GX-2CI-BP-00 module is designed for professional CATV/IPTV headend systems. It is equipped with 2 DVB-C tuners and 2 Common Interface (CI) slots, allowing the reception and decryption of encrypted CATV signals. This module integrates seamlessly with the Fracarro GALAXIA platform, enabling centralized IPTV or RF distribution—ideal for hotels, hospitals, and large-scale building networks.

GX-BP-8T-R01A is an 8-channel DVB-T modulator output module designed for the Galaxia platform. It supports up to 8 DVB-T RF multiplexes and offers easy parameter management via an intuitive HTML-based web interface. The module is hot-swappable and ideal for professional IPTV and RF headend systems in hotels, hospitals, and multi-dwelling buildings.

The GX-BP-16C-R00 is a high-performance 16-channel QAM (DVB-C) modulator module designed for Fracarro's Galaxia IPTV headend platform. It allows for the conversion of up to 16 IP transport streams into DVB-C QAM RF outputs for distribution over coaxial networks. Ideal for hotels, hospitals, campuses, and multi-dwelling units, this module ensures seamless integration with the Galaxia system and supports advanced web-based configuration and management.

The GX-4C2CI-BP-00 module is a professional-grade Quad DVB-C input receiver for Fracarro's Galaxia platform. It features 4 DVB-C tuners and 2 PCMCIA Common Interface slots, allowing conditional access CAMs to decrypt encrypted content from any of the 4 tuners. Ideal for redistribution of cable TV channels over IP networks or coaxial RF, this hot-swappable module ensures maximum flexibility and reliability in commercial IPTV and headend systems.

The GX-4T2CI-BP-00 is a professional-grade 4-channel DVB-T/T2 terrestrial TV receiver module designed for the Galaxia headend system. Equipped with two coaxial RF inputs and two PCMCIA Common Interface (CI) slots, it can receive and decrypt up to four DVB-T/T2 multiplexes (two per RF input). This hot-swappable module ensures continuous operation and seamless integration with IPTV or RF-based digital TV systems. Ideal for hotels, hospitals, and professional IPTV headend installations.

The GX-BOX-DP-SFP is a 1RU modular headend chassis designed specifically for Fracarro’s Galaxia platform. Perfectly suited for IPTV distribution in hotels, hospitals, universities, and large-scale commercial buildings, this chassis features six hot-swappable module slots and forced ventilation for reliable, uninterrupted operation.

The Fracarro GX-BOX-DP is a high-performance modular IPTV chassis, designed for professional-grade applications. It fits a standard 1RU rack and features 4 Gigabit Ethernet RJ45 ports—2 for management and 2 for IP input/output streaming. With built-in dual power supply for high reliability, it ensures stable operation in mission-critical environments.

SIG7804H264RFIP Fracarro 4 HDMI Encoder Modulator to IP & DVB-T Output for Digital MATV & IPTV (287613) is a professional device that converts HDMI audio and video signals into IPTV and digital TV signals across 4 channels. Manufactured by Fracarro and imported from Italy.

3DG-BOX 283156 3DG-BOX Chassis Box and Control unit 6 Slots for plug Module 3DG Series Power supply 184-264Vac, 50-60Hz 105W(max)

3DG-PS-BU 283168 3DG-BOX Series Modular Backup Power supply 220-230Vac, 50-60Hz 135W(max)

3DG-BP-IP OUT 283164 Module 3DG-EVO IPTV multicast/unicast Back Panel 48 pin (Max Bitrate 1000Mbit/Sec) to DVB-IPTV (UDP, RTP/UDP Protocols SAP, IGMP, M3U, DHCP) Multicast groups 64 Unicast or Multicast

3DG-4S2-BP 283163 Module Digital Modulators 4 TP DVB-S/S2 (950-2150MHz ) Input to BP(Back Panel 48 pin) 3DGFLEX Series Trasmodulatrion Modular Headends Programming by Web interface (imported to Thailand supports Biss)

3DG-4S2-4T 283162 Module Digital Modulators 4 TP DVB-S/S2 (950-2150MHz ) Input to 4 TP DVB-T (S2-E69) Output 3DGFLEX Series Trasmodulatrion Modular Headends Max output 95dBµV MER ≥36 dB Programming by Web interface (imported to Thailand supports Biss)

3DG-4ASI-4T 283167 Module Digital Modulators 4 ASI Input to 4 TP DVB-T (S2-E69) Output 3DGFLEX Series Trasmodulatrion Modular Headends Max output 95dBµV MER ≥36 dB Programming by Web interface

SIG7804H264 287430 4 HDMI input to ASI Output (Max bitrate 216 Mbps) Professional encoder Series

Analog/HDMI to ASI Encoder Series – A professional-grade series of encoders designed to convert analog or HDMI signals into ASI (Asynchronous Serial Interface) format, ideal for broadcasting and digital TV headend applications.

D-MATRIX 4S EVO 283132 Digital Modulators 4 TP DVB-S/S2 (950-2150MHz ) Input to 4 TP DVB-T (S2-E69) Output D-MATRIX Series Transmodulation Compact Headends Max output 90dBµV MER ≥36 dB Programming by Web interface or Keyboard and display (imported to Thailand supports Biss)

D-MATRIX 4S FTA 283135 Digital Modulators 4 TP DVB-S/S2 (950-2150MHz ) Input to 4 TP DVB-T (S2-E69) Output D-MATRIX Series Transmodulation Compact Headends Max output 90dBµV MER ≥36 dB Programming by Web interface (imported to Thailand supports Biss)

HMODTV-LT MICRO 287545 HDMI to DVB-T 1 Channel Digital Modulators Input HDMI/RF-Mix Channel select E5-E12 or E21-E69 Max output 90dBµV MER(UHF) 35dB

HMODTV-LT MINI 287546 HDMI to DVB-T 1 Channel Digital Modulators Input HDMI/RF-Mix Channel select E5-E12 or E21-E69 Max output 90dBµV MER(UHF) 35dB

HMODTV-LT 287544 HDMI to DVB-T 1 Channel Digital Modulators Input HDMI/RCA/RF-Mix Channel select E5-E12 or E21-E69 Max output 90dBµV MER(UHF) 35dB

FRPRO LIGHT HD 287523 Programmable Profiler Headends FRPRO HD Series 4 Inputs TV/FM Amplifier Gain FM 35dB VHF >45dB UHF >55dB (Auto AGC Gain adj. >60dB) Channel Convertor >50TP Automatic LTE filtering Output max FM 113dBµV VHF/UHF 108dB Number Filters Matrix 15

FRPRO HD Series 5 Inputs TV/FM Amplifier Gain FM 35dB VHF >45dB UHF >55dB (Auto AGC Gain adj. >75dB) Channel Convertor >50TP Automatic LTE filtering Output max FM 113dBµV VHF/UHF 118dB Number Filters Matrix 32
