SKU : 271171
Categories : SMATV / MATV / CATV system ,
Brand : FRACARRO
Share
| AMP435SSA ABLA | ||
| Product Code | 271171 | |
| Inputs/Outputs | ||
| Inputs | 4 SAT | |
| Outputs | 4 SAT | |
| SAT Section | ||
| Bandwidth | 950-2150 | MHz |
| Gain | Self-adjusted A.B.L.A. 16-36 | dB |
| SAT Tilt Adjustment | 15 | dB |
| AGC | Depends on the set level: 65-85 @101dBµV; 85-105 @121dBµV | dBµV |
| Max Output Level | 101-121 | dBµV |
| Return Loss | 10 | dB |
| SAT-SAT Isolation | 35 | dB |
| Power Consumption | ||
| Power Supply Voltage | 220-240 / 50-60 | Vdc/A |
| Absorption | 550 @12V | mA |
| Max Current Consumption LNB | 900 | mA |
| Maximum Power Supply Current SAT | 2000 | mA |
| Specifications | ||
| Dimensions Power Supply | 120 x 72 x 35 | mm |
| Operating Temperature | -10 to +55 | °C |
| Dimensions and Packaging | ||
| Pieces | 1 | |
| EAN Code | 8016978101627 | |
| Packaging Dimensions | 234 x 166 x 45 | mm |
| Product Dimensions | 160 x 110 x 30 | mm |
| Packaging Weight | 0.81 | kg |
