The FRACARRO AMP435SA ABLA is a programmable terrestrial TV amplifier designed for SMATV and MATV systems, with built-in LTE filtering and automatic level adjustment (ABLA). It allows precise amplification and equalization of up to 4 VHF/UHF inputs, with SAW filters for excellent channel selectivity. It’s ideal for professional installations where signal conditions vary or where future-proofing against LTE/5G interference is required.
Key Features:- Programmable amplifier for terrestrial TV signals
- Supports 4 independent VHF/UHF inputs, configurable and mixable
- Built-in ABLA (Automatic Building Level Adjustment) – maintains constant output level
- High selectivity via integrated SAW (Surface Acoustic Wave) filters
- Integrated LTE filter (rejects 4G/5G interference)
- Output level up to 118 dBµV
- Adjustable gain and equalization for precise signal shaping
- Powered by 12–24V DC, low power consumption
- Compact design, easy to program with programmer or PC
| AMP435SA ABLA |
| Product Code | 271173 | |
| Inputs/Outputs |
| Inputs | 4 SAT | |
| Outputs | 4 SAT | |
| SAT Section |
| Bandwidth | 950-2150 | MHz |
| Gain | Self-adjusted A.B.L.A. 16-36 | dB |
| Slope | 6 | dB |
| AGC | Dependent on the set level: 65-85 @101dBµV; 85-105 @121dBµV | dBµV |
| Max Output Level | 101-121 | dBµV |
| Return Loss | 10 | dB |
| Power Consumption |
| Power Supply Voltage | 220-240 / 50-60 | Vdc/A |
| Absorption | 550 @12V | mA |
| Max Current Consumption for LNBs | 1200 | mA |
| Specifications |
| Operating Temperature | -10 to +55 | °C |
| Dimensions and Packaging |
| Pieces | 1 | |
| EAN Code | 8016978051250 | |
| Packaging Dimensions | 370 x 170 x 85 | mm |
| Product Dimensions | 265 x 120 x 40 | mm |
| Packaging Weight | 1.0 | kg |
