GWN7806(P) Layer 2+ Managed Network Switch
The GWN7806(P) is a high-performance layer 2+ managed network switch with 48 ports that allows small-to-medium enterprises to build scalable, secure, and smart business networks that are fully manageable

  • 48 Gigabit Ethernet ports and 6 10Gigabit SFP+ ports
  • Smart power control to support dynamic PoE/PoE+ power allocation per port for the PoE models
  • Supports deployment in IPv6 and IPv4 networks
  • Reliability features including fault detection, device protection, dual boot, dual system file redundancy, link aggregation, storm control, and more
  • ARP Inspection, IP Source Guard, DoS protection, port security & DHCP snooping
  • Embedded controller to manage switch; GDMS Networking and GWN Manager, Grandstreams cloud and on-premise Wi-Fi management platform
  • Built-in QoS allows for prioritization of network traffic
  • Supports stacking (pending) for easy management of up to 16 switches in one interface while creating redundant backup between multiple devices



Grandstream GWN7806 / GWN7806P
Network ProtocolsIPv4, IPv6, IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3AB, IEEE 802.1p, IEEE 802.1D, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x
PoE StandardsIEEE 802.3af/at
Gigabit Ports48
10Gigabit SFP+ Ports6 (Support DAC cable, max length 5m)
Maximum Number of Supported ModulesSM-10G: 6
MM-10G: 6
RJ45-10G: 3 (RJ45-10G modules must be interval inserted)
Console1
Number of PoE Ports48
Integrated Power Supply60W / 470W
Maximum Output Power Per PoE Port30W
Max Total PoE Output Power400W
Surge Protection± 6KV CM and DM for power
± 4KV CM for network ports
ESD± 12KV for contact discharge
Auxiliary Ports1x Reset Pinhole
Forwarding ModeStore-and-forward
Total Non-blocking Throughput108Gbps
Switching Capability216Gbps
Forwarding Rate160.704Mpps
Packet Buffer16Mb
Network LatencyLess than 4µs
