SKU : 226713 F Connector
Categories : Fracarro FTTx HFC Smatv , TV/SAT Splitter & Tapoff ,
Brand : FRACARRO
Share
| AT14LTE60 | ||
| Code | 226713 | |
| Input no. | 1 | |
| Inputs | VHF + UHF | |
| Frequency | 174 - 790 | MHz |
| Gain | 14 | dB |
| Optical noise figure | 2 | dB |
| Outputs number | 1 | |
| Output level | 115 | dBµV |
| Connectors | F Female | |
| Specifications | ||
| Power supply voltage | 12 | V |
| Absorption | 30 | mA |
| Impedence | 75 | Ohm |
| Operating temperature | -10 to +55 | °C |
| Protection | IP66 | |
| Dimensions and packaging | ||
| Pieces | 1 | |
| EAN code | 8016978095506 | |
| Packaging dimensions | 32 x 22 x 78 | mm |
| Product dimensions | 70 x 20 x 20 | mm |
| Packaging weight | 0.041 | kg |
